MX 2

The vacuum pump operates efficiently at both 120V and 230V, supporting single-phase systems with maximum power installation of 0.36 kW (at 230V) and 0.4 kW (at 120V). It draws a maximum current of 1.56 A at 230V and 3.3 A at 120V, making it suitable for various applications. The sealing bar measures 265 mm, while the available chamber dimensions, including the tank and lid, are 270x154 mm with a height of 179 mm. When the machine lid is open, its dimensions expand to 325x425 mm with a height of 510 mm, and when closed, it measures 325x425 mm with a height of 240 mm. The packaged size is 525x430 mm with a height of 300 mm, and the machine weighs 24 kg net and 27 kg gross, ensuring a compact yet powerful solution for vacuum sealing needs.
